EETI Standard Projected Capacitive Sensors

The quickest way to get started with Projected Capacitive Touch is to order one of our standard Double-Sided-ITO-Glass (DITO) sensors with either a Microchip or EETI touch controller directly from our web site. We also have standard Open Frame Products that can also be ordered directly from our web site. The Open Frame Products include a USB touch controller, an LCD, and an LCD driver board with HDMI and VGA inputs. Our standard products are great for proof-of-concept designs, software development, technology evaluation, and even small production runs.

All of our standard EETI sensors and controllers are available in the list below.  Choose a sensor size, then choose the control board.  The EETI control boards support USB and I2C, although the I2C connector is not populated.  The control boards come preprogrammed to work with a specific sensor.  You cannot swap control boards between two different sensor sizes even if they have the same tail sizes.

There is also a list of accessory items that might be helpful to you including a standard USB cable that connects directly to our EETI control boards.

Information on operating system drivers for our EETI controller boards can be found here.

Sensors and Controllers

Size Part Number Active Area Dimensions USB/I2C
7" 152.40 x 91.44 179.96 x 125.53 x 1.85
8" 174.00 x 104.40 209.20 x 144.56 x 1.85
15.6" 344.20 x 193.59 384.14 x 233.48 x 2.80

Accessories

Part Number Description For use with
Standard USB cable for all USB PCBs All controllers
